Size |
NPS 2″- 72″ |
|
Pressure |
Class 150 – 2500 |
|
Material |
WCB, LCB, WC6, WC9, C12A, CF3/CF3M, CF8/CF8M, A105, LF2, F51, F53, F55, INC 625 |
|
Design & Manufacture Std. |
BS 5155, API 609, MSS SP-67, MSS SP-68 |
|
Face to Face Std. |
BS 5155, API 609, MSS SP-67, MSS SP-68 |
|
End Connection Std. |
ASME B16.5, DIN2543-2545 |
|
Test standard |
ISO5208, BS 6755, API 598 |
|
Structure type |
Flanged, Lug, Wafer, Long and short pattern, with inspection port |
|
Operated way |
Lever, Gear, Pneumatic, Electric, Hydraulic |
|
Size |
NPS 3 ″-42″ |
|
Pressure |
Class 150-300 |
|
Material |
WCB, LCB, WC6, WC9, C12A, CF3/CF3M, CF8/CF8M, A105, LF2, F51, F53, F55, INC 625 |
|
Design & Manufacture Std. |
BS 5155, API 609, MSS SP-67, MSS SP-68 |
|
Face to Face Std. |
BS 5155, API 609, MSS SP-67, MSS SP-68 |
|
End Connection Std. |
ASME B16.5, DIN2543-2545 |
|
Test standard |
ISO5208, BS 6755, API 598 |
|
Structure type |
Flanged, Lug, Wafer, Long and short pattern, with inspection port |
|
Operated way |
Lever, Gear, Pneumatic, Electric, Hydraulic |
